I have been working on resurrecting an old pen plotter. (HP 7440A / HP ColorPro)

It holds 8 little stubby pens.  I have modified/cut the chasis so that long pens can be loaded, and bought some little aluminum pen holders to hold inexpensive ballpoint pen ink tubes/tips.

This is an (incomplete, Plotter's X axis linear rail was apparently dry, and too stiff, causing the printer to abort about 75% through. That's ok, manual inspection of the plot file shows it was never going to actually change pens like it was supposed to anyway) AI generated image produced from Imagine.AI (Very good quality generator, actually!), that I ran through it and DrawingBotsv3-Premium

The pen is a very crappy "It actually came from the front desk at a casino!" ballpoint pen, calibrated to "just barely touch the paper".  It draws like an inexpensive BiC pen, which is why I stole it from work. (It was already stolen once, being a promotional pen from a casino...)



This plotter only accepts letter sized paper, and has a max plottable area of 8x10 inside the 8.5x11 paper. (needs .25" margins on all sides)


I am considering using this machine and software toolchain to make pen-drawn portraiture of my residents for their families. (with permission, of course.)

[King Zultan]

That's pretty cool looking, so is a pen plotter is a computer controlled thing that draws what you tell it to?

[wierd]

Yes.

Mine is an HP 7440A (ColorPro)

It speaks a limited subset of the HP Graphics Language (HPGL), which is human-readable, and talks on a serial port.

In theory, you can control it directly from any oldschool BASIC interface that supports a serial port, since it uses human-readable plain-text command codes. The bread and butter commands with this plotter are:

IN;  (Initialize printer)
DF; (Load printer defaults)
PS(n); Set pen pressure
SP(n); Select Pen
PU(X,Y); (Pen Up, move to location in .01mm increments)
PD(X.Y); (Same as above, but with Pen Down)

Basically, a computer controlled etch-a-sketch


DrawingBotsV3 (Premium!!) has a subprogram to communicate with these old plotters, and is able to produce the volumetric shading needed to use a pen to render a modern pixel-based image into pen strokes. (using a variety of methods)

Free software, like InkScape also can speak HPGL over a serial port, to send paths to such a device, but my plotter does not support the FILL operation, or programmed polygons. (It WOULD with the 'graphics enhancement', but I have been unable to locate one!)
